Description
| Application | |
| CPU | Intel® recommended Pentium® M Processor & Celeron® M processors for micro-FCBGA package |
| Specification | |
| Overall Dimension | 50 x 50 x 22 mm |
| Thermal Resistance | 1.601 °C/W |
| Weight | 110 g |
| Heat Sink | |
| Material | Copper |
| Dimension | 50 x 50 x 13.5 mm |
| Fan | |
| Dimension | 40 x 40 x 10 mm |
| Speed | 5500 rpm |
| Bearing | Dual Ball |
| Rated Voltage | 12 V |
| Power | 1.44 W |
| Air Flow | 4.57 cfm |
| Noise Level | 25.06 dBA |
| Air Pressure | 0.077 inch-H2O |
| Lead Wire Pin Out | Pin1-Black (-) Pin2-Red (+) Pin3-Techometer/Signal output |
