Description
| CPU Socket | F 1207 |
| CPU | AMD® Shanghai & Barcelona processors -Third-Generation Opteron 2300 & 8300 series & Second-Generation Optero |
| Solution | 1U |
| Overall Dimension | 100.0 x 77.0 x 27.5 mm |
| Weight | 430 g |
| Material | Copper Heatsink |
| Fan Dimension | 70 x 70 x 15 mm |
| Speed | 6000 RPM |
| Bearing | 2 Ball Bearing |
| Rated Voltage | 12 V |
| Power | 8.76 W |
| Air Flow | 14.16 CFM |
| Noise Level | 53.56 dBA |
| Air Pressure | 1.809 inch-H2O |
| Lead Wire Pin Out | Pin1-Black (-) Pin2-Red (+) Pin3-Techometer/Signal output |
