Description
Low-Noise 92x25mm PWM Fan, H.C.C.(Heatpipes Contact CPU)Technology HeatPipe CPU Cooler for 3U&Up and Workstation up to CPU power 165 Watts.
| CPU Support | Intel |
|---|---|
| CPU Socket | LGA2011 l LGA2066 (Square Type, 80 x 80mm mounting pitch) |
| Solution | 3U and Up, Workstation |
| Dimensions | 91.0 x 91.0 x 110.0 mm |
| Weight | 530 g |
| Material | Aluminum Fins, 4x Heat Pipes with H.C.C. Technology |
| Fan Dimension | 92 x 25 mm |
| Speed | At Duty Cycle 20%: 1000 RPM At Duty Cycle 50%: 1800 RPM At Duty Cycle 100%: 2500 RPM |
| Rated Voltage | 12V |
| Bearing | 2 Ball Bearing |
| Power | Power At Duty Cycle 20%: 0.96 W At Duty Cycle 50%: 1.44 W At Duty Cycle 100%: 3.0 W |
| Air Flow | Power At Duty Cycle 20%: 17.34 CFM At Duty Cycle 50%: 31.21 CFM At Duty Cycle 100%: 43.36 CFM |
| Noise Level | Power At Duty Cycle 20%: 17.0 dBA At Duty Cycle 50%: 24.78 dBA At Duty Cycle 100%: 31.92 dBA |
| Air Pressure | At Duty Cycle 20%: 0.48 mm-H2O At Duty Cycle 50%: 1.55 mm-H2O At Duty Cycle 100%: 3.0 mm-H2O |
| Lead Wire Pin Out | Lead Wire Pin Out Pin1- (-) Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
